The X-Treme Root Grapple is built for extreme applications including land clearing, heavy brush, logs, and large debris. Constructed with 5/8" thick steel on the top plate, 1/2" on the bottom, and reinforced with 4" square tubing. Features enclosed hydraulic cylinders and shafts for added protection.
We Order our Xtreme Duty Root Grapples with the tines turned Flat. They typically come angled upward. Either style can be ordered to suit your needs.
Specs:
Rated For: 65 HP and above
Overall Depth: 42"
Overall Height: 38"
Top Plate Thickness: 5/8" steel
Bottom Plate Thickness: 1/2" steel
Frame Tubing: 4" square tubing
Cylinders: (2) 2" x 10"
Hydraulic Lines: Routed inside tubing to prevent tears
Mount: Universal skid steer quick attach
Options: Spacer tines
Sizes we typically order - 72”, 78”, 81”, 84”
